| Brand Name: | KAIDUN |
| Model Number: | KDQ-UDC-PTF228(237)01 |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Supply Ability: | 5000 units/year |
Underwater Analogue HD Pan&Tilt Camera
Key Features
Service
|
Aquaculture |
Underwater Photography |
Underwater Video |
Udnerwater Salvage |
Other Application Scenarios:Pipeline Maintenance;Underwater exploration etc
Parameters
| Name | Underwater Analogue HD Pan&tilt Camera |
| Model NO. | KDQ-UDC-PTF228(237)01 |
| Main Parameters | |
| Image Sensor | 2Magapixel Analogue HD COMS/1080p |
| Signal Type | HD Over Coax |
| Resolution | 2 Magapixel |
| SYS | PAL/NTSC |
| Minimal Illumination | 0.01 lux at F1.25600°K |
| Video Output | 1V-75 ohms AHD/CVBS,video signal(Anti-interference technology) |
| Rotation Range | Horizontal360°continuous spin,Vertical direction 0°~180° |
| Antenna Sweep Radius | Maximum in air:5m Minimum in air:60mm |
| Lens | |
| Lens | 2.8/3.7 mm Glass Lens/F1.2 |
| Focus | Electronic motion Focus |
| Function | |
| Function | 3 speed,Low/medium and high speed,dynamic switching 6 high brightness 0.5W white LEDs(50000h lifetime),10 levels of micro dimming |
| General | |
| Material | Stainless Steel /Titanium Alloy |
| Depth Rating | 0-100 m |
| Voltage Supply | 48VDC |
| Temperature | -30℃~+60℃ |
| Size | Φ45*105(not including parts 34mm) |
| Weight | 0.2kg(Stainless Steel) |
| Parts | |
| Packing List | Cable ,Adaptor,Warranty Card ,Certification ,Report |
| Depth | |
| Customization | Sensor(Temperature ,Pressure..) Control Display Screen |
