Underwater Network HD Zoom Camera with wiper
Key Features
Service
Application Scenarios
Other Application Scenarios:Pipeline Maintenance;Underwater exploration etc
Parameters
| Name | 2MP 20X Underwater Network Zoom Camera with wiper |
| Type | KDH-UDW-VL220LW |
| Camera parameters | |
| Sensor Type | 1/2.8”Progressive Scan CMOS |
| Minimum illumination | Color:0.001 Lux @(F1.6,AGC ON);B/W:0. (F1.6,AGC ON) |
| Electronic shutter | 1/25 Seconds to 1/100,000 seconds;Slow shutter |
| Day/Night Mode | Automatic ICR Infrared Filter |
| Lens parameters | |
| Focal length | 5.1-102mm,20x optical zoom |
| Iris | F1.6-F2.86 |
| Horizontal field angle | 51.69-4.58°(Wide Angle-Telephoto) |
| Close range | 100-1500 mm(wide-angle-telephoto) |
| Zoom Speed | Approx.3 Seconds (optical,wide-angle-telescopic) |
| Compression Standards | |
| Video compression standard H.265 Coding type |
H.265/H.264 Main Profile |
| H.264 Encoding type | BaseLine Profile/Main Profile/High Profile |
| Video compression bit rate | 32 Kbps~16Mbps |
| Audio compression standard | G.711A/G.711U/G.722.1/G.726/MP2L2/AAC/PCM |
| Audio compression bit rate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/16-64Kbps(AAC) |
| Image parameters(maximum image size:1920*1080) | |
| Primary stream resolution | 50Hz:25fps(1920*1080,1280*960,1280*720); 60Hz:3Ofps(1920*1080,1280*960,1280*720) |
| Resolution and frame rate of the third stream |
Independent of the primary stream setting,the maximum frequency is 50 Hz:25fps(704*576);60Hz:30 fps (704*576) |
| Image Settings | The saturation,brightness,contrast,and sharpness can be adjusted on the client or browser |
| Backlight compensation | Supported.You can customize regions |
| Exposure mode | Auto Exposure/Iris Priority/Shutter Priority/Manual Exposure |
| Focus mode | Auto Focus/One Focus/Manual Focus/Semi-Automatic Focus |
| Area exposure/focus | Support |
| Anti-shake | Support |
| Day/night mode | Auto,Manual,Timed,Alarm Trigger |
| 3D noise reduction | Support |
| Image overlay | Supports BMP 24-bit image overlay and region customization |
| Region of Interest | Supports three streams and four fixed regions Network function |
| Storage function | Supports the expansion of micro SD/SDHC/SDXC card(256 GB)for local storage.NAS(supported by NFS,SMB,and CIFS) |
| Support Protocol | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,RTCP,NTP,SMTP,SNMP,IPv6 |
| Interface Protocol | ONVIF(PROFILE S,PROFILE G),GB28181-2016,mainstream protocol in China |
| Intelligent computing | |
| Intelligent computing | 2T |
| Interface parameters | |
| External Interfaces | 36-Pin FFC(including the Ethernet port,RS485,RS232,SDHC,Alarm In/Out,Line In/Out,and power supply)USB3.0 |
| General | |
| Material | Optional stainless steel/titanium alloy /industrial plastics |
| Waterproof gradation | 0-50m |
| Power supply | DC24V |
| Operating temperature | -30℃~+60℃ |
| Dimensions | φ128X265mm(34mm connector are not included) |
| Weight | 4.5Kg |
| Accessories | |
| Package | Cable,adapter,warranty card,certificate,suppression report |
| Customizable | Depth (The deepest can be customized 6000m),Sensor (temperature,pressure...),Display control terminal |
