4MP 33X Anti Rust Fixed IP Marine CCTV Camera with wiper
Key Featuers
Service
Application Scenarios
Container Vessel, Bulk Vessel, Oil Tanker, Cruise Vessel, Yacht, Oil/Gas Drilling Platform, Oil Depots, Sea Port
Other application areas:desert drill sites,offshore rigs,mechanical engineering,biogas plants,military,electric power,hydraulic power,railway,metallurgy,natural gas extraction,drilling platform,aerospace,marine,armed police,border defense,vessels,fireworks production,ports etc.
Parameters
| Camera | |
| Image device | 1/2.7"inch line by line scan 4MP CMOS image sensor |
| Optical double | 33X |
| Focal distance | Electric and dynamic zoom,4.5~148.5m m |
| Iris diaphragm | F1.65 (W)~F4.7(T) |
| Field of View (H) | 51.4° ~ 2.5° |
| Field of View (V) | 30.3° ~ 1.4° |
| Field of View (D) | 63.2° ~ 3.0° |
| Shutter | Automatic /manual,1~1/100000s |
| Through the fog | Adaptive fog |
| Noise-signal ratio | >56dB |
| Wide Dynamic | 120dB |
| Minimal Illumination | 0.003lux(F 1.65,AGC ON,color),0.002lux(F1.65,AG CON,black and white) |
| Switch the mode day and night | Automatic,day,night,switching quantity control |
| 3D positioning | Support |
| Anti-shake | Support |
| Detection Distance | 105-3100m |
| Observe Distance | 40-1260m |
| Video Frequency | |
| video coding | H.265,H.264,MJPE G |
| Maximum frame rate | 30 Frames |
| Video stream | Main code stream:2688*1520,2560*1440,2304*1296,1920*1080,1280*720(720P),720*576 (D1),640*360,704*288(2 CIF),352*288(CIF); |
| Auxiliary code stream:1920*1080,1280*720(720P),720*576 (D1),640*360,704*288(2 CIF),352* 288(CIF); Third stream:720*576 (D1),640*360,704*288(2 CIF),352*288(CIF) |
|
| Video code rate | 128Kbps~16Mbps |
| 0SD | Time,cloud head coordinates,multiplier,preset bit,serial port OSD,number of people statistics,network port OSD,picture OSD,environment volume,device longitude and latitude sitting Standard et al |
| Regional Enhancement (ROI) | Eight areas |
| Privacy cover | Black style,Marseille,gram style:8 single scenes,24 multiple scenes |
| Screenshot | Regular grasp,periodic grasp,cruise preset bit grasp,manual grasp |
| Grasp the map at the maximum resolution | 2688*1520 |
| Audio frequency | |
| Audio encoding format | G.7G11U,G.711A |
| Audio sampling rate | G.711U,G.711A:8KHz /16K Hz |
| Memory | |
| Front end storage | Micro SD,up to 256GB |
| Intelligence | |
| Face detection | Support effect priority,speed priority,cycle preferred three face snap preferred mode,support face Angle filtering; Support human face,human body capture,support human face attribute extraction;Face attributes:gender,age,wearing glasses,wearing masks,hat style,hat color |
| Peripheral cloth defense | Support cross-boundary detection,regional invasion,entry area and leaving area;Support motor vehicles,non-motor vehicles,pedestrian target classification detection,capture and distribution |
| Number of statistics | Statistics of human flow:support the statistics of total number,number of entering and number of leaving,support the three-level alarm of the number of stranded,and clear the statistics of the number of support;Personnel density detection:to support the three-level alarm of personnel density |
| Autotracking | It supports the classification and tracking of motor vehicles,non-motor vehicles and pedestrian targets in the screen,and automatically returns to the original position after reaching the preset tracking time |
| Smart Function | |
| Common event | Motion detection,occlusion detection,sound detection,alarm input,and alarm output |
| Network | |
| Networking protocol | L2TP,IPv4,IPv6,IGMP,ICMP,ARP,TCP,UDP,DHCP,RTP,RTSP,RTMP,DNS,DDN S,NTP ,FTP ,UPnP,HTTP,SNMP,SIP |
| Compatible access | ONVIF Profile G,Profile T ,Profile S,GB/T28181,GA/T 1400,API |
| Cache supplement | Support SD card broken network cache supplementary record |
| Interface features | Description(see the Technical Definition Manual for a detailed description) |
| Interface form | 36pinFFC(including network port,power supply,serial port UART_1,serial port UART_2, Alarm In /0ut,Audio In /Out) |
| General | |
| Power | DC12V/POE+/AC100V-240V etc optional,≤18W (The maximum power supply distance of POE+ is 80m.) |
| Dimensions(L*W*H) | 280*185*223mm |
| Net Weight | ≤7.7kg |
| Material | Stainless Steel 316L |
| Working Environment | -40℃~60℃,Humidity:≤100%RH(non-condensing) |
| Strorage Environment | -40℃~60℃,Humidity:s100%RH(non-condensing) |
| Surge Protection | 2KV |
| Ingress Protection | IP68 |
| Inlet Hole Specification | 1 Entry hole G1/2 |
| Installation Method | Wall or column platform installation |
Certificate
Dimension
Accessories
SS316L Exe Type Juction Box Explosion Proof & Anti-corrosion Flexible Hose
