| Brand Name: | KAIDUN |
| Model Number: | MCL-PT005 |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Supply Ability: | 5000 units/year |
| Material | Aluminum Alloy (with powder coating) |
|---|---|
| Protection Class | IP66 |
| Working Temperature | -40℃~+65℃ |
| Working Humidity | <90% |
| Video | IP |
| Visible Resolution | 4MP/8MP optional |
| Visible Focal Length | 55x/86x optical zoom optional |
| Angular Resolution | 0.01° |
| Repeat Positioning Accuracy | ≤0.1° |
| Motor & Transmission Method | Brushless DC Motor,Precision Spur Gear Transmission |
| Rotation Range | Horizontal: 0~360° (0.4°~40°/s) Vertical: -70°~+45° (0.23°~10°/s) |
| Function | Top-mounted Payload (15KG),Gyro Stabilization, Optical Fog Penetration |
| Voltage | DC24V (≤18W) |
| Weight | ≤8kg |
| Dimensions (H*L*W) | 293*274*175mm |
| Mounting | Formal Installation, Four-Point Base Fixation |
