| Brand Name: | KAIDUN |
| Model Number: | MCL-PT004 |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Supply Ability: | 5000 units/year |
| Material | Aluminum Alloy (with powder coating) |
|---|---|
| Protection Class | IP66 |
| Working Temperature | -40℃~+65℃ |
| Working Humidity | <90% |
| Video | IP |
| Optional Matching Scheme | Visible Lens + Thermal Lens Visible Lens + Laser Lens |
| Visible Resolution | 4MP/8MP optional |
| Visible Focal Length | 40x/52x/55x optical zoom optional |
| Thermal Resolution | 640*512 |
| Thermal Length | 20-100mm zoom/15-75mm zoom optional |
| Laser Range | 500m/800m/3000m optional |
| Motor & Transmission Method | Brushless DC Motor,Precision Spur Gear Transmission |
| Rotation Range | Horizontal: 0~360° (0.23°~40.6°/s) Vertical: -70°~+45° (0.23°~10.5°/s) |
| Function | Top-mounted Payload (15KG),Gyro Stabilization, Optical Fog Penetratior Machine, Pedestrian, Non-motor Vehicle and Vessel Recognition |
| Voltage | DC24V (≤55W) |
| Weight | ≤20kg |
| Dimensions (H*L*W) | 315*245*475mm |
| Mounting | Formal Installation, Four-Point Base Fixation |
