Quality 4MP 4mm DNV Approval Marine Grade Anti-Corrosion Fixed IR Camera factory
Quality 4MP 4mm DNV Approval Marine Grade Anti-Corrosion Fixed IR Camera factory

4MP 4mm DNV Approval Marine Grade Anti-Corrosion Fixed IR Camera

Place of Origin: China
Brand Name: KAIDUN
Certification: DNV TA/ATEX/CE/DCC
Model Number: KDM-EX-FL404IR01
Minimum Order Quantity: 1
Packaging Details: Wooden box packaging / cardboard box packaging
Delivery Time: 5-8 week
Payment Terms: T/T
Supply Ability: 5000 units/year
Inquiry Now
Get A Quote
Specifications
Highlight Features

DNV Approval Marine Grade 4MP

,

IR range 30meters

,

DC12V /PoE Power

Material:
Stainless Steel 316L
Resolution:
4MP
Focal Length:
4mm
Net Weight:
3kg
Power:
DC12V/POE Optiona
Dimensions(L*W*H):
152*138*167mm
Product Description

4MP 4mm DNV Approval Marine Grade Anti-Corrosion Fixed IR Camera



Key Features

  • Marine-grade Mini IP Camera system including:
    - Stainless steel 316L Enclosure with Powder Coating
    - 4MP, 4mm fixed lens,
    - IR range 30meters
    - DC12V /PoE Power,
    - IP68
  • Accessories including :
    -1x KDJ008 ATEx Exe Corrosion Proof JB with powder coating
    -1x KDB001DT Anti-shake SS316L Wall Mounting Bracket
    -1x 1.5meters Explosion Proof Hose with 316L connectors

Application Scenarios



Container Vessel, Bulk Vessel, Oil Tanker, Cruise Vessel, Yacht, Oil/Gas Drilling Platform, Oil Depots, Sea Port

Other application areas:desert drill sites,offshore rigs,mechanical engineering,biogas plants,military,electric power,hydraulic power,railway,metallurgy,natural gas extraction,drilling platform,aerospace,marine,armed police,border defense,vessels,fireworks production,ports etc.



Service



You can have the product replaced within 7 days due to quality problem and the quality guarantee period for this product is one year.
You can also get the favorable promotions.
In the following conditions the product is not considered within the quality guaranteescope:
- Client cannot bring forth the quality guarantee card and invoice or receipt of purchasing;
- Improper service conditions,such as unmatched power,ambient temperature,humidity or lightingcaused malfunction;
- Malfunction caused by accident,negligence,disaster incorrect operation or network attack;
- Malfunction or damage in installation,repair,modification or dismantle caused by unauthorizedpersonnel;
- Out of guarantee period.
If you have any dissent on technical service provided by distributor,please lodge acomplaint to the customer's service center of Kaidun.
The quality guarantee card will be validated only after it's stamped by the after-service provider.



Parameters



Type KDM-EX-FLXXXIR01
Material Stainless Steel 316L
Protection Class IP68
Temp.range min -40℃
Temp.range max +60℃
Vibration(0-100Hz) 0.7g
Video IP
Operational Areas Outdoor
Mounting Wall mounted
IR IR
Surface powder coating
Resolution 4MP
Lens 4mm
Image Sensor 1/2.8"Progressive Scan CMOS
Min.illumination Color:0.01 Lux@(F1.2,AGC ON),0.028 Lux@(F2.0,AGC ON),O Lux with IR
CCTV add-on WDR,HLC,illegal login,motion detection ,line crossing detection ,intrution detection etc
Voltage PoE/DC12V
Net Weight 3kg
Certificates DNV TA/ATEX/CE/FCC
EX Mark ExII 2G Exdb op is IIC T6 Gb II 2DExtb op i IIC T80℃ Db IP68 IP66
Intelligent Detection(AI) Motion Detection/Human Detection





Certificate

4MP 4mm DNV Approval Marine Grade Anti-Corrosion Fixed IR Camera4MP 4mm DNV Approval Marine Grade Anti-Corrosion Fixed IR Camera4MP 4mm DNV Approval Marine Grade Anti-Corrosion Fixed IR Camera4MP 4mm DNV Approval Marine Grade Anti-Corrosion Fixed IR Camera



Dimensions



4MP 4mm DNV Approval Marine Grade Anti-Corrosion Fixed IR Camera4MP 4mm DNV Approval Marine Grade Anti-Corrosion Fixed IR Camera

Accessories

       4MP 4mm DNV Approval Marine Grade Anti-Corrosion Fixed IR Camera              4MP 4mm DNV Approval Marine Grade Anti-Corrosion Fixed IR Camera                        4MP 4mm DNV Approval Marine Grade Anti-Corrosion Fixed IR Camera

          Anti-Shake SS316L Bracket             SS316L Exe Type Juction Box         Explosion Proof & Anti-corrosion Flexible Hose
