4MP 22X Anti-Corrosion Bullet IR IP Marine CCTV Camera with Wiper
Key Features
Service
Application Scenarios
Container Vessel, Bulk Vessel, Oil Tanker, Cruise Vessel, Yacht, Oil/Gas Drilling Platform, Oil Depots, Sea Port
Other application areas:desert drill sites,offshore rigs,mechanical engineering,biogas plants,military,electric power,hydraulic power,railway,metallurgy,natural gas extraction,drilling platform,aerospace,marine,armed police,border defense,vessels,fireworks production,ports etc.
Parameters
| Camera | |
| Image device | 1/2.7"Inch line by line scan 4MP CMOS image sensor |
| Optical double | 22x |
| Focal distance | Electric dynamic zoom,from 5.2 mm to 114.4 mm |
| Iris diaphragm | F1.6(W)-F 3.6(T) |
| Shutter | Automatic/manual,1~1/100000s |
| Through the fog | Adaptive fog |
| Noise-signal ratio | >56DB |
| Wide Dynamic | 120DB |
| Minimal illumination | 0.003Lux(F1.65,AGC ON,color),0.004Lux(F1.65,AGC ON,black and white) |
| Switch the mode day and night | Automatic,day,night,switching quantity control |
| 3D positioning | Support |
| Detection Distance | 90-1500m |
| Observe Distance | 40-570m |
| Video frequency | |
| Video coding | H.265,H.264,MJPE G |
| Maximum frame rate | 30 Frames |
| Video stream | Main code stream:2688*1520,2560*1440,2304*1296,1920*1080,1280*720(720P),720*576 (D1),640*360,704*288 (2 CIF),352*288(CIF); Auxiliary code stream:1920*1080,1280*720(720P),720*576 (D1),640*360,704*288(2 CIF),352*288(CIF); |
| Video code rate | 128Kbps~16Mbps |
| 0SD | Time,cloud head coordinates,zoom,preset bits,serial OSD,orientation information,network,0SD,picture OSD,etc |
| Privacy cover | Black /Mosaic styles:up to 4 single scenes,and up to 243D rule scenes |
| Screenshot | Support timing grasp map,periodic grasp map,cruise preset bit grasp map |
| Grasp the map at the maximum resolution | 1920*1080 |
| Audio frequency | |
| Audio encoding format | G.7G 11U,G.711A |
| Audio sampling rate | G.711U ,G.711A :8KHz /16K H z |
| Memory | |
| Front end storage | Micro SD,up to 256GB |
| Smart Function | |
| Common event | Motion detection,occlusion detection,and sound detection |
| Network | |
| Networking protocol | L2TP,IPv4,IPv6,IGMP,ICMP,ARP,TCP,UDP,DHCP,RTP,RTSP,RTMP,DNS,DDN S,NTP,FTP,UPnP,HTTP,SNMP,SIP |
| Compatible access | ONVIF Profile G ,Profile T ,Profile S,GB/T28181,GA/T 1400,API |
| Cache supplement | Support SD card broken network cache supplementary record |
| Interface features | Description(see the Technical Definition Manual for a detailed description) |
| Interface form | 36PinFFC(including network port,power supply,serial UART _1,serial UART_2,Alarm In /0ut,Audio In/0ut) |
| Common event | Motion detection,occlusion detection,sound detection,alarm input,and alarm output |
| Network | |
| Networking protocol | L2TP,IPv4,IPv6,IGMP,ICMP ,ARP,TCP,UDP,DHCP,RTP,RTSP,RTMP,DNS,DDN S,NTP ,FTP ,UPnP,HTTP,SNMP,SIP |
| Compatible access | ONVIF Profile G,Profile T ,Profile S,GB/T28181,GA/T 1400,API |
| Cache supplement | Support SD card broken network cache supplementary record |
| Interface features | |
| Interface form | 36PinFFC(including network port,power supply,serial port UART_1,serial port UART_2,Alarm In/0ut,Audio In/0ut) |
| General | |
| Power | DC12V±25% /POE+/AC100V-240V etc optional,≤18W(The maximum power supply distance of POE+ is 80m) |
| Dimensions(L*W*H) | 280*185*343mm |
| Net Weight | ≤8.8kg |
| Material | Stainless Steel 316L |
| Working Environment | -40℃~60℃,Humidity:≤100%RH(non-condensing) |
| Strorage Environment | -40℃~60℃,Humidity:s100%RH(non-condensing) |
| Surge Protection | 2KV |
| Ingress Protection | IP68 |
| Infrared Distance | 50-100m |
| Inlet Hole Specification | 1 Entry hole G3/4 |
| Installation Method | Wall or column platform installation |
Certificate
Dimension
Accessories
SS316L Exe Type Juction Box Explosion Proof & Anti-corrosion Flexible Conduit
