CCS Type Approval SS316L 8MP Dual-Spectrum Bullet Marine CCTV Camera
Product Profile
The MC466T is a Dual-Spectrum Bullet Marine CCTV Camera Certified according to CCS type approval and EN62676,EN60945,The special bracket structure allows this camera to be fixed and rotated at multiple angles. The thermal imaging core enables it to observe changes in the temperature of objects.
Parameters
|
Material |
Stainless Steel 316L |
|
Protcetion Class |
IP66 |
|
Temp.range min |
-40℃ |
|
Temp.range max |
+70℃ |
|
Video |
IP |
|
Operational Areas |
Outdoor |
|
Mounting |
Wall mounted,column installtion |
|
Surface |
Powder coating |
|
Thermal Resolution |
640*512 |
|
Thermal Focal Length |
35mm |
|
Visible Resolution |
8MP |
|
Visible Focal Length |
4.8~48mm,10× Zoom |
|
Image Sensor |
1/2.8”progressive Scan CMOS |
|
FOV |
65°×50° |
|
Functions |
Motion detection,occlusion detection sound,alarm input and alarm output |
|
Voltage |
DC12V power supply |
|
Weight |
≤5kg |
|
Dimensions(L*W^H) |
188*213*210mm |
|
Certificates |
CCS Type Approval |
Dimension
Certificate
Service
Accessories
Explosion Proof & Anti-corrosion Flexible Conduit Anti-Corrosion Junction Box Stainless Steel Joint Connection
