| Brand Name: | KAIDUN |
| Model Number: | KDG003 |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Supply Ability: | 5000 units/year |
| Material | Double-layer 304/316L Stainless Steel |
|---|---|
| Protection Class | IP66 |
| Working Temperature | -10℃~+150℃C/+200℃(with refrigeration tube) |
| Working Humidity | <95%(non-condensing) |
| Video | IP |
| Thermal Resolution | 384*288,640*512 etc |
| Pixel Size | 17μm |
| Spectral Range | 8~14μm |
| Comperssed Air Pressure | 0.2~0.4Mpa |
| Compressed Air Flow Rate | 0.3~0.7m³/min(0.7 m³/min at an air pressure of 0.4 MPa) |
| Temperature Museurement Range | -20°C to 150°C / 0°C to 550°C |
| Temperature Museurement accuracy | ±2°C or ±2% of the reading(whichever is larger). |
| Voltage | DC12V |
| Dimensions | 360*150*145mm |
| Weight | ≤4.5kg |
| Mounting | Stainless Steel Wall-mounted,Pole Installation, etc. |
