| Brand Name: | UTP |
| Model Number: | UTP7524GE-POE-4GF |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Supply Ability: | 5000 units/year |
| Material | Metal |
|---|---|
| IP Video Input | 32-ch |
| Operational Areas | Indoor |
| Software | Managed |
| Copper Ports | 24* 10/100/1000Base-T PoE RJ45 (Auto-MDI/MDI-X) |
| POE Standard | IEEE802.3af 15.4W, IEEE802.3at 30W |
| Power Consumption | <420W (POE consumption; POE budget: 390W) |
| Net Weight | 4.35kg |
| Type | 24 Port POE Switch |
|---|---|
| Material | Metal |
| Temperature Range | -20℃ to +60℃ |
| Vibration (1-100Hz) | 0.7g |
| IP Video Input | 32-ch |
| Operational Areas | Indoor |
| Mounting | in KDRACK system |
| Software | Managed |
| Copper Ports | 24* 10/100/1000Base-T PoE RJ45 (Auto-MDI/MDI-X) |
| SFP Ports | 4*1000 Base-X SFP (Mini-GBIC) |
| Console Port | 1*RJ45-R232 serial port (115200, 8, N, 1) |
| OOB Port | 1*10/100Base-TX RJ45 (only used to Web management) default IP: 192.168.1.200 name: admin password: admin |
| Exchange Capacity | 56Gbps/Non-blocking |
| POE Standard | IEEE802.3af 15.4W, IEEE802.3at 30W |
| Power Consumption | <420W (POE consumption POE budget: 390W) |
| Voltage | Internal power adapter AC100-240V 50/60HZ |
| Net Weight | 4.35kg |
You can have the product replaced within 7 days due to quality problems. The quality guarantee period for this product is one year.
You can also get favorable promotions.
The product is not considered within the quality guarantee scope in the following conditions:
If you have any dissent on technical service provided by distributor, please lodge a complaint to the customer's service center of Kaidun.
The quality guarantee card will be validated only after it's stamped by the after-service provider.
