4MP 30X Marine Anti-Corrosion Crane Damping Starlight IR IP Camera

4MP 30X Marine Anti-Corrosion Crane Damping Starlight IR IP Camera

Key Features

    This Crane CCTV system meets the requirements of Crane operators.The Crane ctv system is to be installed in hazardous areas and is primarily used on offshore cranes,supplied with up to 3-4 cameras providing clear view of the cargo,the wire drum and pedestal enhancing hoisting operations.


    Whereas building structures,objects,distances and light conditions used to represent big challenges for the crane operator,the Crane CTV makes even the most challenging tasksfeasible.With a crane camera installed to overlookthe topside of the load and crane hook assembly,valuable information is relayed to the crane operator via hismonitor.ffered a clear view of the load on the monito the traditional dificulties of manoeuvring the load safely andeficiently have been reduced significantly.


    The optional Automatic object Tracking feature automaticallyzooms in on the predefined objec,tracking the payload during hoisting or lowering,keping the object a constant size on the sren.This s practical for checking clearances,correct wire spooling et.The interface unit uses an network feedback signal from the wire drum.The Crane Camera overlookin the crane hook assembl is suspended from the crane structure via an interated oil amper.The design keps the camera in a stable vertical position even when the crane boom is tited.The Spring damping and movement gyroscope stabilization.absorbs shocks and vibration protecting the camera and ensuring stable pictures.


    Depending on the model,the Crane CCTV system includes either a joystick or a push-button based control.All camera functions ssuch as iris,zoom,focus and camera selections can be operated with the joystick.The joystick can be removed from the control box and installed into other panels if required.

     A compact central unit links the system together as wellas providing room for the electronics and the power supply for the camera station.

    This crane damping CTV camera is developed foroffshore surveilance system.It s featured as toget stable video,andwil noteffect by crane moving or working

• Black Light Full-Color Camera: Achieves ultra-low-light full-color and no-light full-color imaging through the AI ISP image enhancement algorithm.
• AI AF Self-developed Deep Learning Algorithm Module: Enables faster focusing speed and more stable focusing performance.
• Built-in 2T Intelligent Computing Power: Supports in-depth algorithm learning to enhance the performance of intelligent event algorithms.
• Maximum Resolution: Up to 4MP (2688*1520), capable of outputting real-time full HD images at 2688*1520@30fps.
• Illumination Performance: 0.0001 Lux/F1.6 (color mode), 0.00005 Lux/F1.6 (black-and-white mode), 0 Lux with IR (infrared) support.
• Zoom Capability: Supports 30x optical zoom and 16x digital zoom.
• Gyroscopic Image Stabilization: Equipped with gyroscope anti-shake function.
• ICR Infrared Cut Filter: Features automatic switching to realize true 24/7 day-and-night monitoring.
• Excellent Low-Light Performance: Delivers fine and delicate image quality under low illumination conditions.
• 3A Control Support: Includes automatic white balance, automatic exposure, and automatic focusing.
• Adaptive Functions: Supports backlight compensation and automatic electronic shutter to adapt to different monitoring environments.
• Image Enhancement Technologies: Supports 3D digital noise reduction, strong light suppression, anti-shake, and wide dynamic range.
• Fog Penetration: Supports optical fog penetration to significantly improve image quality in foggy weather; also offers automatic fog penetration and intelligent fog penetration modes, which adjust fog penetration capability automatically based on scenarios.

Application Scenarios

Other application areas:desert drill sites,offshore rigs,mechanical engineering,biogas plants,military,electric power,hydraulic power,railway,metallurgy,natural gas extraction,drilling platform,aerospace,marine,armed police,border defense,vessels,fireworks production,ports etc.
