| Brand Name: | KAIDUN |
| Model Number: | KDC-EX-□□□E□□□□ |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Supply Ability: | 5000 units/year |
IECEEX Approval Explosion Proof Fixed Dual Light Zoom Camera
Key Features
Technical Parameters
| Material | Stainless Steel 316L |
| Protcetion Class | IP68 |
| Temp.range min | -40℃ |
| Temp.range max | +70℃ |
| Video | IP |
| Operational Areas | Outdoor |
| Mounting | Wall mounted,Column Installation |
| Surface | Powder coating or electric polishing |
| IR Range | 100m(300m optional) |
| Thermal Resolution | 256*192/384*288/640*512/1280*1024 etc |
| Thermal Focal Length | 4.1mm/6.9mm/7.8mm/13mm/19mm/25mm/35mm etc |
| Visible Resolution | 2MP,4MP,8MP etc |
| Visible Zoom | 20x/30X/33X/40x/72x etc |
| Temperature Measurement Range | -20℃~+550℃/-20℃~+650℃/0℃~2000℃ etc |
| Optional matching scheme | Visible Lens +|R/Visible Lens +Observation-type Thermal / VisibleLens + Temperature Measurement-Type Thermal |
| Voltage | DC24V/POE++/AC100-240V power optional |
| Weight | ≤18.6kg |
| Dimensions(L*W*H) | Short Type:235*367*230.5mm Medium Type:285*367*230.5mm Long Type:335*367*230.5mm |
| Ex Grade | Ex db I Mb Ex db IIC T6 Gb,Zone 1&2 Ex tb ⅢIC T85'℃ Db,Zone 21&22 |
| Certificates | IECEX ATEX Certification Body:DNV |
Application Scenarios
|
Oil & Gas |
Refineries & Fuel Depots |
Surevillance & Security |
Chemie & Pharma |
Oil Tankers |
Other application areas:desert drill sites,offshore rigs,mechanical engineering,biogas plants,military,electric power,hydraulic power,railway,metallurgy,natural gas extraction,drilling platform,aerospace,marine,armed police,border defense,vessels,fireworks production,ports etc.
