Explosion Proof CCTV Camera
>
Explosion Proof Pan/Tilt IR Optical 38X Zoom Camera

Explosion Proof Pan/Tilt IR Optical 38X Zoom Camera

Brand Name: KAIDUN
Model Number: KDC-EX-PTVIEa2b38
MOQ: 1
Payment Terms: T/T
Supply Ability: 5000 units/year
Detail Information
Place of Origin:
China
Certification:
DNV IECEEX
Ex Grade:
Ex D IIC T6 Gb,Zone 1&2 Ex Tb IIIC T85℃ Db,Zone 21&22
Material:
Stainless Steel 316L
Resolution:
2MP
Focal Length:
38x
Pan/Tilt Speed:
0.1°~45°/sec(Max 45°/sec)
IR Range:
150m(300m Optional)
Packaging Details:
Wooden box packaging / cardboard box packaging
Supply Ability:
5000 units/year
Highlight:

ir explosion proof cctv camera

,

38x ir bullet camera

,

38x explosion proof cctv camera

Product Description

Explosion Proof Pan/Tilt IR Optical 38X Zoom Camera



Key Features

  •  EX Certification:IECEx/ATEX/DNV
  •  EX Grade:Ex d IIC T6 Gb,Zone 1&2 Ex tb IIIC T85℃ Db,Zone 21&22
  •  Gear transmission and worm gear transmission methods are available.
  •  Electro-polished AISI 316L stainless steel
  •  Germanium Glass &Tempered Glass
  •  Ingress Protection Rating:IP68
  •  Ambient Temperature:-40℃~+60℃
  •  Pan/Tilt Speed:0.1°~45°/sec(Max 45°/sec)
  •  Pan Rotation Angle:360°Endless,Tilt Rotation Angle:±90°
  •  2MP 38x Optical Zoom Camera(4MP/5MP/6MP/8MP etc  resolution optional,22x/33x/36x etc Zoom optional)
  •  IR Range:150m(300m optional)



Other application areas:desert drill sites,offshore rigs,mechanical engineering,biogas plants,military,electric power,hydraulic power,railway,metallurgy,natural gas extraction,drilling platform,aerospace,marine,armed police,border defense,vessels,fireworks production,ports etc.



Service

You can have the product replaced within 7 days due to quality problem and the quality guarantee period for this product is one year.
You can also get the favorable promotions.
In the following conditions the product is not considered within the quality guaranteescope:
- Client cannot bring forth the quality guarantee card and invoice or receipt of purchasing;
- Improper service conditions,such as unmatched power,ambient temperature,humidity or lightingcaused malfunction;
- Malfunction caused by accident,negligence,disaster incorrect operation or network attack;
- Malfunction or damage in installation,repair,modification or dismantle caused by unauthorizedpersonnel;
- Out of guarantee period.
If you have any dissent on technical service provided by distributor,please lodge acomplaint to the customer's service center of Kaidun.
The quality guarantee card will be validated only after it's stamped by the after-service provider.
